Biosafety Fume Hood

About Biosafety Fume Hood

BIO SAFETY CABINET CLASS II A2

The Class II, Type A2 cabinet recirculates approximately 70% of the air through a supply filter, and exhausts approximately 30% of the air through an exhaust filter to the room or through a canopy exhaust connection to a facility exhaust system. HEPA-filtered air descends through the work zone in a vertical, unidirectional flow.

STANDARD FEATURES

v Cabinet made of GI powder coated with inner skin Stainless Steel 304

v Pre-Filter Assemblage for Multi-Dispose particle predominantly in the size range of 5- 20 microns

v HEPA Filter

v Airflow: Designed for 0.45m/s to 0.65 m/s when measure across the entire filters space during the rated life cycle of filters.

v Cleanliness level class 100

v Fluorescent lamp

v Flow Ratio: Class II Type A2: 70% recirculation 30% Exhaust

v UV- light---- 30watts.

v Front Door: 8MM thickness polycarbonate, vertically sliding, balanced with counter weight.

v Noise level : 65 +/- 5 db

v Vibration level : less than 2.5 um (0.0001)

v Power supply : 230 V Ac

v Stainless steel work table

v Gas cock

v Extra power outlet switch

v Color RAL9002

o 4 x 2 x 2 feet

v Inner Dimension: 610 x 610 x 610 mm (W x D x H)

Overall Dimension : 750 x 850 x 2300 mm (W x D x H)
